S32205 S32304 S31803 DIN1.4462 022cr23ni5mon 2507 S32750 1.4410 S32760 Duplex Steel Plate 2205 Stainless Steel Plate
S32205 2205 Duplex Steel Plate 2205 Stainless Steel Plate 2205 duplex series Stainless steel plate/sheet/coil/circle/str
Basic Info
| Model NO. | S32205 2205 S31803 S32750 2507 |
| Surface Treatment | Pickling |
| Transport Package | Wooden Pallet Wooden Box |
| Specification | 1220*2440, 1500*3000, 1500*6000, 2000*6000mm |
| Origin | China |
| HS Code | 7219340000 |
| Production Capacity | 50000kgs |
Product Description
S32205 2205 Duplex Steel Plate 2205 Stainless Steel Plate2205 duplex series Stainless steel plate/sheet/coil/circle/strip Superior corrosion resistance to 316L and 317L combined
with high strength. Excellent stress corrosion and abrasion resistance. Typically and widely used in piping heat exchangers,
gas scrubbers, fans, chemical tanks, flowlines, marine and refinery applications, Chemical process vessels, Pulp mill digesters,
bleach washers, chip pre-steaming vessels, Food processing equipment, Oil field piping and heat exchangers, Flue gas
desulfurization equipment and other fields.
| GradeSeries | Steel Grade | Standard | Dimension(mm) | ||
| Thickness | Width | Length | |||
| DDS 2205DuplexStainlesSteel | S31803S32205 | AISIUNS NO. | 0.3-180 | 1000-2000 | 1000-8000 |
| 1.4462 | EN NO. | ||||
| SAF2205SS2377 | Sweden | ||||
| 00Cr22Ni5Mo3N | China GB | ||||
| UR 45N+ | France | ||||
| DDS 2207Duplex Stainless Steel | S32750 | USA-AISI | 0.3-180 | 1000-2000 | 1000-8000 |
| 1.4410 | Germany | ||||
| SAF2507 | Sweden | ||||
| UR 47N+ | France | ||||
Alloy 2205 Duplex Stainless Steel Plate Technique Specifications:
| Grade(Duplex Stainless steel) | Chemical Composition (%) | ||||||||
| C | Si | Mn | P | S | Ni | Cr | Mo | N | |
| S31803(SAF2205)00Cr22Ni5Mo3N | 0.03Max | 1.00Max | 2.00Max | 0.030Max | 0.02Max | 4.5~6.5 | 21.0~23.0 | 2.5~3.5 | 0.08~0.20 |
| S32750SAF250700Cr22Ni7Mo4N | 0.03 Max | 0.80 Max | 1.20Max | 0.035 Max | 0.02Max | 6.0~8.0 | 24.0~26.0 | 3.0~5.0 | 0.24~0.32 |
| Grade | As(Mpa) | Ab(Mpa) | Elongation% | Hardness | |
| HB | HRC | ||||
| S31803(SAF2205)00Cr22Ni5Mo3N | ≥450 | ≥620 | ≥25 | ≤290 | ≤30.5 |
| S32750SAF250700Cr22Ni7Mo4N | ≥550 | ≥800 | ≥15 | ≤310 | ≤32 |
